Aquawrap®

Aquawrap® is a low cost composite system for use in repair and reinforcement of existing mechanical systems, structures and piping. Furnished factory-impregnated with the proprietary 22-77 resin system, it is odorless and non-flammable. Aquawrap® is ready to apply, right out of the bag and cures by way of a chemical reaction with field-applied water. When cured, it is a very durable, high strength material that is impervious to fuels, most chemicals and solvents. It permanently bonds to a wide variety of surfaces such as metals, composites, concrete, plastics, and wood.

Our custom formulated system has been thoroughly tested by our in-house lab, outside testing facilities, universities, and by customers themselves. This extended array of acceptance has earned Aquawrap® an excellent reputation within the industry. Our ability to control our production and meet demand is second-to-none.

Aquawrap® is the perfect solution for quick repairs on DOT regulated pipelines.

General Characteristics

• Tg. 288° F
• Working Time 30 minutes nominal, after water application
• Cure Time 60 minutes nominal, after water application
• Chemical Resistance Resistant to acetone, MEK, toluene, gasoline, ethyl alcohol and many others
• Adhesion 1,000 psi (lap shear) to abraded carbon steel, using BP-1 Primer
• Tensile Strength 42,000 psi for the Standard G-03 Fabric (equivalent to 575 lbs/per ply/per inch of width)
• Compressive Strength 28,500 psi for the Standard G-03 Fabric
• Interlaminar Shear 2,900 psi for the Standard G-03 Fabric

Features

• Low Cost
• Uses a Water-Activated Polyurethane Resin
• Simple and Easy to Use
• Cures in Wet Conditions and Underwater
• Excellent Toughness - Resists Cracking
• Many Different Widths and Lengths
• Heat Resistant to 288° F
• Non-Hazardous
• Working Time of nearly 1-hour - Perfect for Large Installations
• High Strength and Excellent Long Term Performance
• Manufactured in Azusa, CA USA by Field Applied Composite Systems, LLC

Sizes

• 2" Wide x 5-feet • 2" Wide x 12-feet
• 3" Wide x 10-feet • 3" Wide x 30-feet
• 4" Wide x 15-feet • 4" Wide x 30-feet • 4" Wide x 50-feet
• 6" Wide x 15-feet • 6" Wide x 30-feet • 6" Wide x 60-feet • 6" Wide x 90-feet
• 10" Wide x 30-feet • 10" Wide x 60-feet • 10" Wide x 90-feet
• 10" Wide x 120-feet • 10" Wide x 150-feet
• 12" Wide x 30-feet • 12" Wide x 60-feet • 12" Wide x 90-feet
• 12" Wide x 120-feet • 12" Wide x 150-feet

Custom lengths are available.

We are always available for discussions on our manufacturing capabilities. If you require a product that you don't see here, please let us know. Our business model allows for unique and challenging projects and we may be able to help you with your special projects.
